DP-A20, аппарат напыления полиуретановой пены

Model No. DP-A20 Mode of driving Pneumatic (Air-driven) Mixing volumetric ratio 1:1 Maximum output volume 8kgs/min (20 lbs/min) Maximum temperature of fluid 90°C (194°F) Maximum working pressure 120bar / 1740psi Compressed air pressure 3-8bar (43-120psi) Air consumption @7bar 0.6CBM/min Air compressor output: 0.8cbm/min Heater power 8000W Maximum hose length 60m Spraying materials: 80~100square meters per hour Power parameters Single-phase 220V 50Hz 30A Net weight 120kgs Overall size 60cm x 60cm x 110cm Packing dimension: 70cm x 80cm x 125cm Contents in package: Machine 1 set, Transfer pump 2 sets, Heating hose 15m (50ft) 800watt, Heating whip hose 1.5m (5ft), Self-cleaning spray/injecting gun 1 set, Repair kit 1 set, Cleaning fluid 1 kg, DOP 1 kg

DP-A20 PU polyurethane foam spraying equipment * Designed for spraying the foaming (A. ISO isocyanate ; B. Polyol ) two components mixing and spraying. * Powered by air compressor with max.8bar and 1cbm/min output * This A20 polyurethane foam spraying machine has accurate mixing for A+B two components * Accurate temperature control and easy monitoring for result in good quality of sprayer material * Easy to use, easy to clean, easy to move, high productivity foam sprayer machine. * Stable performance pneumatic air motor for long lifetime and suitable for complex spraying jobs * Stainless steel precise proportioning pump with long lifetime * Innovated two-circuit heating pipes adopt the most advanced wrapping internal heating, it will maintain the required temperature and viscosity for the perfect components mixing ratio and finish.
